HUAWEI TE80 Videoconferencing Endpoint
Administrator Guide
4 Display Device and Camera
Issue 02 (2014-03-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
44
Parameter
Description
Setting
position
on the screen.
This parameter is available only when
Automatic layout mode is set to PiP.
NOTE
Only the main output port supports this
parameter.
right corner.
Display local
video
Display remote
video
Display
Presentation
Specify the content to be display through
a port.
You can select these three parameters for
video output ports, except Main output
interface and Auxiliary output port.
Choose whether to display
the local and remote videos
and presentations based on
your needs.
Step 4 Select Save.
----End
4.2.2 Adjusting the Picture Offset
If you find that the displayed video deviates from its normal position, adjust the picture offset.
Prerequisites
A VGA or YPbPr video signal source is connected to the endpoint.
Background
VGA or YPbPr Image offset may occur in video input or output, such as when the computer
desktop is displayed on the display.
Procedure
Step 1 Choose Advanced > Settings > Video > Image Offset.
Step 2 Select a video input or output port.
You can adjust the picture offset only for a video input or output port to which a VGA or YPbPr video
signal source is connected. The ports to which other video signal sources are connected are unavailable
for adjustment.
Step 3 Select Horizontal offset or Vertical offset and move the slider to make adjustments.
----End
4.2.3 Adjusting the Sampling Phase
If a blurring or slight jitter issue occurs in the video shown on the display device, adjust the
sampling phase.
