HUAWEI TE80 Videoconferencing Endpoint
Administrator Guide
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Figure 5-2 A single VPM220 working in stereo mode
To set the mode for cascading VPM220s:
Step 1 Choose Advanced > Settings > Audio.
Step 2 Based on the actual conditions in the conference room, set Microphone array position to
Horizontal or Vertical.
The default value is Horizontal.
Step 3 Select Save.
----End
5.1.2 Connecting a VPM220W
The endpoint can be connected to a HUAWEI VPM220W wireless microphone array
(VPM220W) over a Wi-Fi network. The TE50 and TE40 can be connected to only one
VPM220W while the TE80 can be connected to one or two VPM220Ws.
When installing a VPM220W, do not point any microphone towards the speaker.
Status Indicators on the VPM220W
VPM220W status indicators quickly provide VPM220W working status.
There are five indicators on top of the VPM220W and a charging status indicator on the
charger base. Table 5-6 describes these indicators.
Table 5-4 Status indicators on the VPM220W
All three microphone indicators are steady
red.
All the three microphones are turned off.
All three microphone indicators are steady
blue.
All the three microphones are turned on.
All three microphone indicators are off.
The power switch of the VPM220W is turned
off.
