Connecting the VPM220W to the Endpoint
TThe endpoint can be connected over a Wi-Fi network to a VPM220W for sound pickup.
Before connecting the VPM220W to the endpoint, you must enable the Wi-Fi hotspot and set
Wi-Fi parameters as follows:
Set Identity authentication mode to WPA-PSK or WPA2-PSK.
Enable DHCP and set Start IP address and End IP address.
For details, see Setting Wi-Fi Hotspot Parameters.
To connect the VPM220W to the endpoint:
Step 1 Press the power button at the bottom of the VPM220W to power it on.
The VPM220W automatically searches for an available Wi-Fi network.
If the VPM220W was once connected to the endpoint, the connection between these two
will automatically set up, so you can skip the following steps.
If you are using the VPM220W for the first time or moving it outside the connected
Wi-Fi network range, go to Step 2 and Step 3.
Step 2 Hold and press the button on top of the VPM220W for at least 3 seconds.
A confirmation dialog box is displayed on the remote controlled UI.
Step 3 Select OK.
The VPM220W then performs the Wi-Fi Protected Setup (WPS) Push Button Configuration
(PBC) authentication with the videoconferencing endpoint in order to obtain an IP address.
----End
5.1.3 Setting Audio Parameters
Before using your endpoint to join a conference, set the audio parameters to gain the best
possible audio experience.
Procedure
Step 1 Choose Advanced > Settings > Audio. Set the audio parameters described in Table 5-7.
Table 5-5 Audio input parameters
MIC 1
MIC 2 (available only
for the TE80)
Adjusts the microphone
volume at your site. When
you adjust this microphone
volume, the volume heard at
remote sites is adjusted
accordingly.
These parameters are selected
by default.
Adjusts the input volume of
the RCA port at your site.
When you adjust this input
volume, the volume heard at
These parameters are selected
by default.
