ideoconferencing Endpoint
Administrator Guide
D
Menus
Issue
02
(
2014
-
03
-
30
)
Huawei Propr
ietary and Confidential
Copyright © Huawei Technologies Co., L
td.
161
Only the TE80 supports 4E1 functions.
168
170
Table of Contents
About this Document
3
Table of Contents
5
Overview
9
Definition of an Endpoint Administrator
10
Requirements for an Endpoint Administrator
10
Safety Precautions
11
How to Obtain Help
17
Basic Configuration and Verification
18
Powering on or off the Endpoint
18
Using the Wizard
20
Verifying the Basic Configuration
21
Call Test
21
Sound Test
22
Image Test
22
Power Management
23
Network
26
Connecting to an IP LAN Network
26
Checking Status Indicators of the LAN Port
26
Setting IP Parameters
27
Setting H.323 Parameters
30
Setting SIP Parameters
32
Setting Wi-Fi Parameters
35
Connecting to a 4E1 Network
39
Inserting a 4E1 Interface Card
39
Checking Status Indicators on the 4E1 Ports
41
Setting 4E1 Parameters
41
Display Device and Camera
43
Connecting a Display Device
43
Configuring a Display Device
47
Configuring Video Output
47
Adjusting the Picture Offset
52
Adjusting the Sampling Phase
52
Setting Video Parameters
53
Switching between Screen Layouts
55
Connecting a Camera
56
Configuring Video Input
57
Selecting and Controlling a Camera
59
Setting Camera Presets
60
Microphone and Speaker
62
Connecting an Audio Input Device
62
Connecting a VPM220
63
Connecting a VPM220W
65
Setting Audio Parameters
67
Connecting an Audio Output Device
70
Connecting a Speaker
70
Placing an External Speaker
70
Adjusting the Speaker Volume
70
Connecting a Tuning Console
70
Adjusting Audio Effects
70
Enjoying Stereo Audio
72
Conference
73
Experiencing a Dual-Stream Conference
74
Designating the Dual Streams
74
Sharing a Presentation
75
Viewing the Combined Picture of the Presentation and the Video
75
Experiencing an MSUC Conference
76
Joining an Authentication Conference
78
Joining an HD-Video Conference over an IMS Network
80
Scheduling a Conference
83
Controlling a Conference
83
Conference Control for a Non-Chair Site
84
Conference Control for the Chair Site
85
Recording a Conference
88
Managing the Address Book
89
Configuring the Network Address Book
89
Managing the Local Address Book
92
Importing and Exporting an Address Book
94
Customizing a Site Template
95
Managing Captions
97
Specifying Caption Settings
97
Creating a Banner or Caption
99
Security
100
Setting the Administrator Password
100
Enabling Encryption
101
Supporting Remote Logins
102
Setting the Upgrade Password
104
Setting the Air Content Sharing Password
104
Screen Customization
106
Customizing the Home Screen
106
Customizing Onscreen Status Icons
108
Customizing Conference Control Functions to be Displayed
108
Customizing the Option Bar
109
Embedded Web Management Interface
110
Web Browser
111
Logging in to the Endpoint Web Interface
112
Getting to Know Web Interface Functions
113
Importing and Exporting Settings
113
Importing License Files
114
Downloading an Air Content Sharing Client
114
Multi-View
116
Customizing Shortcut Bar and Desktop Icons
117
Accessing the Site Map
117
Importing a Certificate
117
Monitoring the Video
118
Using the Virtual Remote Control
118
Maintenance
119
Checking the Working Environment Periodically
119
Checking the Endpoint Periodically
120
Viewing System Status
120
Querying System Information
121
Querying Logs
121
Upgrading
123
Automatic Upgrade
124
Tool Upgrade
125
Upgrading the Endpoint Using the Bootrom System
128
Upgrading the Endpoint on Its Web Interface
129
Troubleshooting
130
Fault Diagnostics
130
Troubleshooting
133
Restoring Default Settings
143
Feature Configuration
144
Setting the Number Keys and Power Key on the Remote Control
145
Setting the Parameters for Placing and Answering Calls
145
Setting Advanced Conference Parameters
147
Setting SNMP Parameters
151
Setting Qos Parameters
153
Setting Network Diagnostics Parameters
155
Setting Network Diagnostics Parameters
156
Ports on the Rear Panel
159
A E1 and T1 Grounding Criteria
160
B Technical Specifications
161
C Status Icons
165
D Menus
168
E Terminology
170
F Acronyms and Abbreviations
176
