9.1 Installing Lithium Batteries
Prerequisites
● Before installing lithium batteries, ensure that the cabinet anchor bolts are
tightened.
● Install lithium batteries at the lower layer and then the upper layer.
Procedure
Step 1 Secure a lithium battery to the rack.
● At least two persons are required to move a lithium battery.
● Before pushing a lithium battery into the cabinet, reset the handles on both
sides of the battery to prevent the support bars from being stuck.
Figure 9-1 Securing a lithium battery
Step 2 Install the lithium battery ground cable.
PowerCube 1000 (STC, Saudi Arabia, ICC800-A1-C2,
ESC800-A1)
Installation Guide 9 Installing Batteries and Cables
Issue 02 (2021-09-28) Copyright © Huawei Technologies Co., Ltd. 97
