Figure 9-2 Installing the ESM ground cable

----End

9.2 Installing Battery Cables

5 KW Scenario

Step 1 Install the battery power cables.

NO TICE

Install the negative power cables for batteries and then the positive ones.

PowerCube 1000 (STC, Saudi Arabia, ICC800-A1-C2,

ESC800-A1)

Installation Guide 9 Installing Batteries and Cables
