2 Solution Scenarios
Table 2-1 Solutions scenarios
Application Scenario Category Cabinet Conguration Component Conguration
Solar-Diesel Hybrid Scenario (5
kW DC load power)
ICC800-A1-C2 ● PV Module Support
● 445 W PV Module x 36 pcs
● SJB-0601A x 4 pcs
● Reused DG
● PVDU-150A1 x 2 pcs
● AIU03-100C
● GIM01C2
● M48500N1
● PSU x 7 pcs
● SSU x 4 pcs
● 4G antenna
● ESM-48100A6 x 16 pcs
Solar-Diesel Hybrid Scenario (8
kW DC load power)
ICC800-A1-C2 + ESC800-
A1
● PV Module Support
● 445 W PV Module x 60 pcs
● SJB-0601A x 7 pcs
● Reused DG
● PVDU-150A1 x 4 pcs
● AIU03-100C
● GIM01C2
● M48500N1
● PSU x 8 pcs
● SSU x 7 pcs
● 4G antenna
● ESM-48100A6 x 27 pcs
PowerCube 1000 (STC, Saudi Arabia, ICC800-A1-C2,
ESC800-A1)
