Huawei PowerCube 1000 User Manual

10.7 Installing DC Output Power Cables for the
ETP48600-C5B1
Prerequisites
D ANGER
Switch o all load circuit breakers before installing the power cables.
Procedure
Step 1 Install DC output power cables.
Figure 10-16 Installing DC output power cables
(1) DC load
NO TE
Connect DC power cables to the circuit breaker that controls LLVD based on the load
importance and capacity. The preceding gure is for reference only.
----End
PowerCube 1000 (STC, Saudi Arabia, ICC800-A1-C2,
ESC800-A1)
Installation Guide 10 Installing Cables
Issue 02 (2021-09-28) Copyright © Huawei Technologies Co., Ltd. 117
