5.3 Installation Space Requirements
The power cabinet and battery cabinet have the same installation dimensions. The
following gure uses the power cabinet ICC800-A1-C2 as an example.
Figure 5-1 Installation dimensions (ICC800-A1-C2)
The installation dimensions are for reference only. Determine the dimensions based on the
site situation.
PowerCube 1000 (STC, Saudi Arabia, ICC800-A1-C2,
ESC800-A1)
Installation Guide 5 Installation Preparations
Issue 02 (2021-09-28) Copyright © Huawei Technologies Co., Ltd. 66
