Huawei PowerCube 1000 User Manual

Checking Electrical Connections
Table 11-3 Electrical connection checklist
No. Check That Result
1 All the ground cables prepared onsite contain
copper core wires and have correct diameters. No
switches or fuses are installed on the cables and no
short-circuit occurs.
□ Yes □ No
2 Ground cables, AC input power cables, and internal
cables are connected in accordance with the circuit
diagram and screws are fully tightened. No short-
circuit occurs on power inputs or outputs.
□ Yes □ No
3 Power cables and ground cables are not coiled and
extra parts are cut o.
□ Yes □ No
4 Connectors for power cables and ground cables are
soldered or crimped securely.
□ Yes □ No
5 Bare cables and terminal handles are completely
wrapped with heat-shrink tubings.
□ Yes □ No
6 Flat washers and spring washers are securely
installed for all OT terminals, and all OT terminals
are intact and properly connected.
□ Yes □ No
Cable Checklist
Table 11-4 Cable checklist
No.
Check That Result
1 All cable joints are secured properly, especially
signal cables and the cables to the bottom of the
cabinet.
□ Yes □ No
2 Cables are bound neatly, and cable ties are secured
evenly and properly in the same direction.
□ Yes □ No
3 Power cables, protection cables, and signal cables
are bound separately.
□ Yes □ No
4 Cables are routed in a way convenient for
maintenance and capacity expansion.
□ Yes □ No
5 The cable tie tails on indoor cables are cut smoothly
from the root, and the cable tie tails on outdoor
cables are cut with a margin of 3 mm to 5 mm.
□ Yes □ No
6 Unused ports are protected. □ Yes □ No
PowerCube 1000 (STC, Saudi Arabia, ICC800-A1-C2,
ESC800-A1)
Installation Guide 11 Installation Verication
Issue 02 (2021-09-28) Copyright © Huawei Technologies Co., Ltd. 120
