Figure A-5 Positions for installing oating nuts for a 3 U module
Figure A-6 Positions for installing oating nuts for a 4 U module
Step 2 Install oating nuts using a at-head screwdriver.
NO TICE
When installing oating nuts, wear protective gloves and do not exert excessive
force. Otherwise, the at-head screwdriver may hurt your hand or damage the
device.
Figure A-7 Installing a oating nut
----End
