Model Image
S5348TP-
SI-DC
S5324TP-
PWR-SI
S5348TP-
PWR-SI
1. ESD jack
1. Rear card slot 3. RPS power jack 4. Ground screw 5. Switch
6. AC jack 7. DC jack 8. Fan module 9. Power supply unit slot
1.4 ESD Jack
This section describes the functions of the ESD jack on the S5300.
The S5300 has an electromagnetic discharge (ESD) jack on the chassis.
When installing the S5300, wear an ESD wrist strap. Connect the ESD wrist strap to the ESD
jack on the chassis, as shown in Figure 1-2.
Figure 1-2 ESD jack
1.5 System Configuration
Table 1-6 System configuration
Item
Parameter
Processor S5300C-EI: 533 MHz
S5300C-SI: 800 MHz
S5300TP-SI: 800 MHz
1 Overview of the S5300
Quidway S5300 Series Ethernet Switches
Hardware Description
1-10 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 01 (2011-01-30)
