7.1 SFP Optical Module (FE) Attributes
This section describes the attributes of an SFP optical module (FE).
Table 7-1 SFP optical module (FE) attributes
Item Description
Transmission
distance
2 km
Center
wavelength
1310 nm
Transmitting
power
-19.0 dBm to -14.0 dBm
Receiver
sensitivity
-30.0 dBm
Overload power -14.0 dBm
Extinction ratio 10 dB
Connector type LC
Fiber type Multi-mode
NOTE
The SFP optical module (FE) is applicable to only the 100M SFP optical interfaces or 100M/1000M SFP
optical interfaces.
7.2 ESFP Optical Module (FE) Attributes
This section describes the attributes of an ESFP optical module (FE).
Table 7-2 ESFP optical module (FE) attributes
Item
Description
Transmission
distance
15 km 15 km
(single-
mode
bidirectional
fiber)
15 km
(single-
mode
bidirectional
fiber)
40 km 80 km
Center
wavelength
1310 nm Tx: 1310 nm
Rx: 1550 nm
Tx: 1550 nm
Rx: 1310 nm
1310 nm 1550 nm
Transmitting
power
-15.0 dBm to
-8.0 dBm
-15.0 dBm to
-8.0 dBm
-15.0 dBm to
-8.0 dBm
-5.0 dBm to
0 dBm
-5.0 dBm to
0 dBm
