2.1 Power Supply Configuration
This section describes the power supply configuration on the S5300.
PoE Power Supply
The downlink electrical interfaces of S5300 PoE switches provide PoE power. Each interface
provides a maximum of 30 W power and supports a maximum of 100 m power supply distance.
The S5300 can transmit both current and data on a pair of signal cables.
PoE power supply units are classified into two types: 500 W current sharing power supply and
250 W current sharing power supply.
Power Supply Unit PoE Power Device Power
500 W current sharing power
supply
369.6 W 120 W
250 W current sharing power
supply
123.2 W 120 W
The S5300 PoE switches include:
l S5348TP-PWR-SI, S5352C-PWR-SI, and S5352C-PWR-EI:
Each switch provides two power supply unit slots. Each slot accommodates a 500 W or
250 W power supply unit. The power supply configurations are shown in the following
table.
Power Supply Unit
PoE Power Maximum Number of
Interfaces
250 W current
sharing power
supply
- 123.2 W
l 802.3af: 8
l 802.3at: 4
500 W current
sharing power
supply
- 369.6 W
l 802.3af: 24
l 802.3at: 12
250 W current
sharing power
supply
250 W current
sharing power
supply
246.4 W
l 802.3af: 16
l 802.3at: 8
500 W current
sharing power
supply
500 W current
sharing power
supply
739.2 W
l 802.3af: 48
l 802.3at: 24
l S5324TP-PWR-SI, S5328C-PWR-EI, and S5328C-PWR-SI:
Each switch provides two power supply unit slots. Each slot accommodates a 500 W or
250 W power supply unit. The power supply configurations are shown in the following
table.
2 Power Supply Unit
Quidway S5300 Series Ethernet Switches
Hardware Description
2-2 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 01 (2011-01-30)
