Item Description
Overloa
d power
0 dBm -3.0
dBm
-3.0
dBm
-3.0
dBm
-3.0
dBm
-3.0
dBm
-3.0
dBm
-9.0
dBm
Extincti
on ratio
9.0 dB 9.0 dB 6.0 dB 6.0 dB 8.5 dB 9.0 dB 9.0 dB 8.0 dB
Connect
or type
LC
Fiber
type
Multi-
mode
Single-mode
NOTE
The ESFP optical module (GE) is applicable to only the 1000M SFP optical interfaces or 100M/1000M
SFP optical interfaces.
7.4 ESFP CWDM-SFP Optical Module
This section describes the attributes of an ESFP CWDM-SFP optical module.
Table 7-4 ESFP CWDM-SFP optical module attributes
Item
Description
Transmi
ssion
distance
80 km
Center
wavelen
gth
1471
nm
1491
nm
1511
nm
1531
nm
1551
nm
1571
nm
1591
nm
1611
nm
Transmi
tting
power
0 dBm to 5.0 dBm
Receiver
sensitivi
ty
-28.0 dBm
Overloa
d power
-9.0 dBm
Extincti
on ratio
8.5 dB
Connect
or type
LC
Fiber
type
Single-mode
