Table 4-19 describes the types and functions of interfaces on the ETPC.
Table 4-19 Types and functions of interfaces on the ETPC
Type Quantity Description
PCI-E electrical interface 2 The ETPC provides two 12 Gbit/s electrical
interfaces to transmit and receive services.
4.6.4 Technical Specifications
Table 4-20 describes the technical specifications of the ETPC.
Table 4-20 Technical specifications of the ETPC
Parameter Description
Dimensions 200.0 mm x 69.0 mm x 22.0 mm (depth x width x height)
Power
consumption
0.5 W
Weight 0.2 kg
4.7 ETPB-Extended Rear Card
This section describes the functions, appearance, indicators, interfaces, and technical
specifications of the extended rear card.
4.7.1 Functions and Applications
4.7.2 Appearance
4.7.3 Technical Specifications
4.7.1 Functions and Applications
Functions
The ETPB extended rear card must be used together with the E4GF/E4GFA or E4XY front card
to provide four SFP GE interfaces or SFP+ 10GE interfaces.
Applications
The ETPB can be inserted into the S5328C-EI, S5352C-EI, S5328C-EI-24S, S5328C-SI,
S5352C-SI, S5328C-PWR-SI, S5352C-PWR-SI, S5328C-PWR-EI, or S5352C-PWR-EI for
interface extension.
4 Interface Cards
Quidway S5300 Series Ethernet Switches
Hardware Description
4-16 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 01 (2011-01-30)
