Huawei Quidway S5328C-EI Hardware Description

Figure 5-10 Multimode fiber with LC/PC connectors
Pin Assignments
Table 5-10 describes the pin assignments of an optical fiber.
Table 5-10 Pin assignments of an optical fiber
Local End Terminal
Signal
Direction
Remote End Terminal
Optical interface Tx terminal -> Optical interface Rx terminal
Optical interface Rx terminal <- Optical interface Tx terminal
Fiber Selection Criterion
Table 5-11 lists the criteria for selecting optical fibers. Table 5-12 lists common optical
connectors.
Table 5-11 Fiber selection criterion
Parameter
Criterion
Length Survey result
Quidway S5300 Series Ethernet Switches
Hardware Description 5 Cables
Issue 01 (2011-01-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
5-13
