Item Description
Cable type
l 227 IEC 53 (RVV)-300 V/500 V
l Rated voltage: 300 V/500 V
l Standards compliance: 227 IEC 53 (RVV)
Conductor cross-sectional
area
3 x 1.0 mm
2
Fireproof level GB18380.1
5.3 Ground Cables
A ground cable protects the device from lightning strike and electromagnetic interference.
Applications
A ground cable connects the chassis to the ground.
Appearance
Figure 5-4 shows the appearance of a ground cable.
Figure 5-4 Appearance of a ground cable
Specifications
Table 5-3 lists the specifications of a ground cable.
Table 5-3 Specifications of a ground cable
Item
Description
Cable type Power cable
Quidway S5300 Series Ethernet Switches
Hardware Description 5 Cables
Issue 01 (2011-01-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
5-5
