NOTE
The ESFP CWDM-SFP optical module is applicable to only the 100M SFP optical interfaces or 1000M
SFP optical interfaces or 100M/1000M SFP optical interfaces
7.5 XFP Optical Module (10GE) Attributes
This section describes the attributes of an XFP optical module (10GE).
Table 7-5 XFP optical module (10GE) attributes
Item Description
Transmission
distance
0.3 km 10 km 40 km 80 km
Center
wavelength
850 nm 1310 nm 1550 nm 1550 nm
Transmitting
power
-7.3 dBm to -1.0
dBm
-6.0 dBm to -1.0
dBm
-1.0 dBm to 2.0
dBm
0 dBm to 4.0
dBm
Receiver
sensitivity
-7.5 dBm -14.4 dBm -15.0 dBm -24.0 dBm
Overload power -1.0 dBm 0.5 dBm -1.0 dBm -7.0 dBm
Extinction ratio 3.0 dB 6.0 dB 8.2 dB 9.0 dB
Connector type LC
Fiber type Multi-mode Single-mode
7.6 SFP+ Optical Module (10GE) Attributes
This section describes the attributes of an SFP+ optical module (10GE).
Table 7-6 SFP+ optical module (10GE) attributes
Item
Description
Transmission distance 0.3 km 10 km 40 km
Center wavelength 850 nm 1310 nm 1550 nm
Transmitting power -7.3 dBm to -1.0
dBm
-8.2 dBm to 0.5 dBm -4.7 dBm to 4.0 dBm
Receiver sensitivity -11.1 dBm -12.6 dBm -14.1 dBm
Overload power -1.0 dBm 0.5 dBm -1.0 dBm
Quidway S5300 Series Ethernet Switches
Hardware Description 7 List of Optical Modules
Issue 01 (2011-01-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
7-5
