No. Indicator Identifier Status Description
Red
l Two power
supply units are
installed properly,
but not switched
on.
l The power supply
units are switched
off.
l The card power
and PoE power
are abnormal.
Orange
If a single power
supply unit is
installed, the PoE
power is out of range.
If two power supply
units are installed, the
card power or PoE
power is out of range.
3
System status
indicator
SYS Off The system is not
operating.
Green The system is not
operating properly or
is starting.
Orange The system is
performing self-
check during startup.
Blinking green The system is
operating properly.
Red After registering, the
system does not
operate properly, or a
power alarm, fan
alarm, or temperature
alarm is generated.
4 Mode
indicator
- Off The service interface
indicator is in the
default mode
(STAT).
6 List of Indicators
Quidway S5300 Series Ethernet Switches
Hardware Description
6-8 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 01 (2011-01-30)
