Figure 3-35 Removing large covers
– The quantity of holes in the above gure is for reference only.
– If holes are drilled for routing cables, attach grommet strips on the hole edges to
protect cables.
Step 11 Connect ground cables and power cables.
For the screw specications and torque used for connecting cables in a bottom cable
routing scenario, refer to the top cable routing scenario. This section only shows the cable
routes in the bottom cable routing scenario.
UPS5000-E-(30 kVA–120 kVA)-FM
User Manual 3 Installation
Issue 03 (2022-01-30) Copyright © Huawei Technologies Co., Ltd. 74
