MAX200 Instruction Manual 6-3
1-99
PARTS LIST
Part
Item
Number Description Designator Qty.
029319 Panel, Control SA
1 041536 PCB, interlock display SA 1
009063 Diode, LED, amber LED 1-7 7
2 005041 Switch, toggle DPDT S1 1
3 022008 Gauge, pressure 0-100 psi PG1 1
4 022008 Gauge, pressure 0-100 psi PG2 1
5 006038 Valve, needle .188 orifice V6 1
6 006027 Valve, needle .125 orifice V5 1
7 001222 Panel, control 1
8 005121 Pushbutton, green, illmn. PB1 1
9 005122 Pushbutton, red, extended PB2 1
10 005088 Holder, lamp 1
005168 Bulb, 28VDC 1
005089 Lens, white for 005088 1
11 - Not applicable to hand torch system.
12 - Not applicable to hand torch system.
13 029360 Panel, thumbwheel/machine delay SA 1
14 005123 Thumbwheel S3 1
15 009604 Resistor, variable, 100 K, 1 turn R9 1
To Next Page
