PARTS LIST
Recommended Spare Parts
Power Supply
Part
Number Description Designator
005044 Switch, toggle SPDT S1
005121 Pushbutton, green, illmn. PB1
005122 Pushbutton, red extended PB2
005088 Holder, lamp -
005168 Bulb, 28 VDC -
005089 Lens, white -
009604 Resistor, variable, 100 K, 1 turn R9
027080 Fan, 225 CFM, 120 VAC, 50/60 Hz M2
027079 Fan, 450-550 CFM, 120 VAC, 50/60 Hz M4
027080 Fan, 225 CFM, 120 VAC, 50/60 Hz M3
041151* PCB, THC motherboard PCB10
041186* PCB, SA-THC PCB9
041143 PCB, Control PCB7
005102 Thermostat, 160°C, 6 Amp TS1
006014 Valve, solenoid V1
005093 Switch, pressure, 0-90 psi PS1
129118 Chopper SA, CH130 CE/LVD CH1/CH2
041534 PCB, power distribution PCB6
008322 Fuse, 8 Amp, 250 VAC -
008317 Fuse, semiconductor, 125 Amp, 250 V F3, F4
003021 Relay, 120 VAC CR1
029202 Sensor, current CS1
027137 Filter, coolant, deionizing -
011025 Filter/regulator FR1
011031 Filter element (used with 011025) -
011027 Gauge, high pressure -
029323 Switch, water temperature, 162°F TS2
029326 Switch, level LS1
029361 Switch, flow, 0.5 gpm FS1
028872 Coolant, propylene glycol 30%/
deionized water 70% (standard mixture)
028873 Coolant, propylene glycol 100%
* Power Supplies with THC
Hand Torch and Torch Leads
Part
Number Description Designator
120045 PAC200T 90° (cutting) Torch Main Body -
020908 PAC200E 65° (gouging) Torch Main Body -
029865 Leads SA:PAC200T/E Torch/PS 25 ft -
