MAX200 Instruction Manual 6-15

9-99

PARTS LIST

Rear Wall Outside – MAX200 Power Supply

Part

Item Number

Description Designator Qty.

129252 Pump Motor Subassembly 1

1 128385 Kit, Replacement Motor, 1/3 HP M1 1

2 128384 Kit, Replacement Pump, 70 GPH 1

3 031122 Drive Coupling, Pump to motor 1

129383 Valve Subassembly (w/ elec connectors) 1

4 006046 Valve, Sol 240V 3/8 NPT NC V7 1

029361 Flowswitch Subassembly (w/ elec connector) 1

5 005119 Flowswitch, 0.5 GPM FS1 1

6 006053 Valve, Check 1/3 PSI, 1/4 NPTM 1

7 027136 Heat Exchanger, Water/Air MX1 1

8 027139 Filter Housing, 10" X 3/8 NPT 1

9 027005 Filter, Element 1

10 011025 Filter Regulator 1

11 011027 Gauge, High Press (for 011025) 1

12 002304 Reservoir, coolant 1

13 022036 Gauge, liquid level 1

14 129618 Level Switch Subassembly, 1/2 NPT LS1 1

15 029323 Temp Switch Subassembly, 162 Deg F TS2 1

16 006099 Bib drain valve 1/4 NPT 1
