6-24 MAX200 Instruction Manual

PARTS LIST

PAC200E Gouging Torch Consumable Parts Kit 028751

Part Number Description

Qty

028751 Parts Kit: PAC200E

001067 Box:Gray Plastic 1

015015 Adapter:1/4NPT X #6 Male 90 Brass 1

015145 Adapter:1/4NPT X G-1/4-BSPP Brass 1

015146 Adapter:1/4NPT X G-3/8-BSPP Brass 1

015147 Adapter:1/4NPT X G-1/2-BSPP Brass 1

015193 Cap:#6 Brass 1

020607 Swirl Ring:MAX200 Air/N2/H35 1

020891 Shield:PAC200E Torch 1

020918 Shield:PAC200T 200A 1

020933 Electrode:PAC200E Torch 5

220021 Electrode:MAX200 Air/Oxy 5

020934 Nozzle:PAC200E Torch N2/H35 5

020615 Nozzle:MAX200 Air/H35 Gouging 5

020608 Nozzle:MAX200 .086 200A Air/N2/H35 5

027055 Lubricant:Silicone 1/4-Oz Tube 1

027194 Nozzle Wrench:MAX200/HT2000 1

044027 O-Ring:BUNA 70DURO 1.301X.070 2

027347 Tool:Water Tube Replacement 1

Trigger Torch 25 – Foot Lead Assembly (Torch to Power Supply)*

Item Part Number Description Qty

029865 Leads SA:PAC200T/E Trch/PS 25 ft 1

1 024375 Hose:200T/E Cap Sensor Trch/PS 1

2 024194 Hose Assy:3/16 Red LH 1

3 023714 Cable: 200T/E Water Cooled Blue 1

4 023716 Cable: 200T/E Water Cooled Red 1

5 023715 Cable: 200T/E Shield Gas 1

6 047203 Cable, 16-1 Pair 1

7 005094 Push Button Switch: Torch 1

– 074069 Splice 2

8 024197 Sheath: MAX200 Hand Torch Leads 25' 1

* Note: If leads longer than 25 feet are needed, use extended leads (see page 6-25).
