6-20 MAX200 Instruction Manual
16
PARTS LIST
PAC200T (90°) Cutting Torch Assembly (no leads)
Item Part Number
Description Qty
073190 PAC200T (90°) Cutting Torch Assembly 1
1 002244 Safety Trigger: PAC120/200T/E Tch 1
2 128904 Kit: PAC200T/E (90°) Torch Handle Replacement 1
3 002519 Boot: PAC200T/E Torch Handle 1
4 075365 P/S, #6X3/4, PH, Pan 6
5 120045 PAC200T (90°) Torch Main Body 1
020963 Water Tube:PAC200T Electd Cool 1
6 044027 O-Ring:Buna 1.301X.070 2
7 027254 Spring, Trigger, PAC120/200T/E Torch 1
220021 Electrode: MAX200 Air/Oxygen 1
020607 Swirl Ring: MAX200 Air/N2/H35 1
020608 Nozzle: MAX200 .086 200A Air/N2/H35 1
020915 Shield Cap: PAC200T Cutting Torch 1
020918 Shield: PAC200T 200A 1
PAC200T (90°) Cutting Torch Assembly with 25 Ft Lead
Item Part Number Description Qty
073189 PAC200T (90°) Cutting Torch Assembly 25 ft 1
1 002244 Safety Trigger: PAC120/200T/E Tch 1
2 128904 Kit: PAC200T/E (90°) Torch Handle Replacement 1
3 002519 Boot: PAC200T/E Torch Handle 1
4 075365 P/S, #6X3/4, PH, Pan 6
5 120045 PAC200T (90°) Torch Main Body 1
020963 Water Tube:PAC200T Electd Cool 1
6 044027 O-Ring:Buna 1.301X.070 2
7 027254 Spring, Trigger, PAC120/200T/E Torch 1
8 029865 Leads SA:PAC200T/E Torch/PS 25 ft 1
220021 Electrode: MAX200 Air/Oxygen 1
020607 Swirl Ring: MAX200 Air/N2/H35 1
020608 Nozzle: MAX200 .086 200A Air/N2/H35 1
020915 Shield Cap: PAC200T Cutting Torch 1
020918 Shield: PAC200T 200A 1
PAC200T Cutting Torch Consumable Parts Kit 028750
Part Number Description Qty
028750 Parts Kit: PAC200T
001067 Box:Gray Plastic 1
015015 Adapter:1/4NPT X #6 Male 90 Brass 1
