5-8 MAX200 Instruction Manual
MAINTENANCE
Removal and Replacement of Torch Lead Assembly
Note: To change length
of torch lead assemblies, see Increase or Decrease Torch Lead Length
on page 5-9.
Perform the following procedure to remove and replace entire
lead assemblies.
Removal
1. Disconnect the torch lead assembly from the power supply by reversing the Connecting the Torch Lead
Assembly procedure on page 3-14.
2. Disconnect the torch from the torch lead assembly as described in the Removal and Replacement of Torch
procedure on page 5-6.
Replacement
1. Connect the torch lead assembly to the power supply by referring to the Connecting the Torch Lead Assembly
procedure on page 3-14.
2. Connect the torch lead assembly to the torch by referring to the Removal and Replacement of Torch procedure
on page 5-6.
