WIRING DIAGRAMS
7-2 MAX200 Instruction Manual 15
Battery
Cap, polarized
Cap, non-polarized
Cap, feed-thru
Circuit breaker
Coax shield
Current Sensor
Current sensor
Diode
Door interlock
Fan
Feedthru LC
Filter, AC
DC supply
Fuse
Ground Clamp
Ground, Chassis
Ground, Earth
IGBT
Inductor
LED
Light
Pin
Plug
PNP Transistor
Potentiometer
Push Button,
Normally Closed
MOV
Push Button,
Normally Open
Receptacle
Relay, Coil
Relay, Normally Closed
Relay, Normally Open
Relay, Solid State, AC
Relay, Solid State, DC
Relay, Solid State, Dry
SCR
Shield
Shunt
Spark Gap
Switch, Flow
Resistor
