Hypertherm Powermax65 SYNC Reference Guide

Serial Communication Programmer Reference Guide
22 810400 Reference Guide Powermax65/85/105 SYNC
Table 3 – Torch type and lead length
Table 4 – Plasma power supply type
Example request and response
Request from CNC:
:010430000001CA<CR><LF>
High Byte
(Torch Type ID)
Torch Typ e
0x00 Hand torch with 7.6 m (25-foot) lead
0x01 Hand torch with 15 m (50-foot) lead
0x02 Hand torch with 23 m (75-foot) lead
0x04 Machine torch with 4.6 m – 7.6 m (15-foot – 25-foot) lead
0x05 Machine torch with 10.7 m – 15 m (35-foot – 50-foot) lead
0x06 Machine torch with 23 m (75-foot) lead
Low Byte
(Type ID)
Plasma Power Supply Type
0x00 Powermax65 SYNC 200 V – 600 V CSA
0x01 Powermax65 SYNC 380 V CCC / 400 V CE
0x02 Powermax85 SYNC 200 V – 600 V CSA
0x03 Powermax85 SYNC 380 V CCC / 400 V CE
0x08 Powermax105 SYNC 200 V – 600 V CSA
0x09 Powermax105SYNC 230V–400V CE
0x0A Powermax105SYNC 380VCCC/400V CE
Value Description
: Start of message
01 Plasma power supply node address
04 Read Registers
3000 First register address (0x3000)
0001 Quantity of registers to read (0x0001 = 1):
• 0x3000 (torch and plasma power supply identification)
CA LRC
<CR><LF> End
