Powermax65/85/105 SYNC Reference Guide 810400 31
Example request and response
Request from CNC:
:0104301A0001B0<CR><LF>
Response from plasma power supply:
:01040201F404<CR><LF>
Value Description
: Start of message
01 Plasma power supply node address
04 Read Registers
301A First register address (0x301A)
0001 Quantity of registers to read (0x0001 = 1):
• 0x301A (active fault code)
B0 LRC
<CR><LF> End
Value Description
: Start of message
01 Plasma power supply node address (confirmed)
04 Read Registers (confirmed)
02 Quantity of bytes in the Data segment (2)
01F4 0x01F4 = 500 (fault code 0-50-0)
The cartridge is off the torch. Or, the cartridge was
removed with the torch-disable switch set to the
green “ready to fire” ( ) position.
04 LRC
<CR><LF> End
