Hypertherm Powermax65 SYNC Reference Guide

Serial Communication Programmer Reference Guide
16 810400 Reference Guide Powermax65/85/105 SYNC
List of Powermax65/85/105 SYNC addresses
SYNC
Address
Description Unit
Recommended Modbus
Function (hex)
Old
Address
Request: Read the ID of the SYNC torch, torch lead, and plasma power supply
0x3000 Torch and plasma power supply identification
High byte: torch ID
Low byte: SYNC ID
N/A 04 (Read Registers) N/A
Request: Read the permitted plasma power supply settings
0x3001 Permitted operating mode setting
High byte: mode high
Low byte: mode low
N/A 04 (Read Registers) N/A
0x3002 Permitted minimum output current (A) setting Amperes 04 (Read Registers) 0x2099
0x3003 Permitted maximum output current (A) setting Amperes 04 (Read Registers) 0x209A
0x3004 Permitted minimum gas pressure setting psi
04 (Read Registers) 0x209C
0x3005 Permitted maximum gas pressure setting psi 04 (Read Registers) 0x209D
Request: Read the plasma power supply settings
0x3010 Operating mode setting
High byte: 0x00
Low byte: mode
N/A 04 (Read Registers) N/A
0x3011 Output current (A) setting Amperes 04 (Read Registers) N/A
0x3012 Gas pressure setting psi 04 (Read Registers) N/A
Request: Read the actual output of the plasma power supply
0x3018 Actual output current (A) Amperes 04 (Read Registers) N/A
0x3019 Actual gas pressure output at valve psi 04 (Read Registers) 0x204C
0x301A Active fault code N/A 04 (Read Registers) 0x2098
Request: Read the total cut counts for this plasma power supply
0x3028 Total number of starts (bytes 1 and 0) Number 04 (Read Registers) N/A
0x3029 Total number of starts (bytes 3 and 2) 04 (Read Registers) N/A
0x302A Cumulative pilot arc time (bytes 1 and 0) Seconds 04 (Read Registers) 0x209E
0x302B Cumulative pilot arc time (bytes 3 and 2) 04 (Read Registers) 0x209F
0x302C Total number of arc transfers (bytes 1 and 0) Number 04 (Read Registers) N/A
0x302D Total number of arc transfers (bytes 3 and 2) 04 (Read Registers) N/A
0x302E Cumulative arc transfer time (bytes 1 and 0) Seconds 04 (Read Registers) N/A
0x302F Cumulative arc transfer time (bytes 3 and 2) 04 (Read Registers) N/A
