Hypertherm Powermax65 SYNC Reference Guide

Serial Communication Programmer Reference Guide
Powermax65/85/105 SYNC Reference Guide 810400 17
Request: Read the 16-character unique identification (UID) number for the installed cartridge
0x3030 UID (bytes 0 and 1) N/A 04 (Read Registers) N/A
0x3031 UID (bytes 2 and 3) N/A 04 (Read Registers) N/A
0x3032 UID (bytes 4 and 5) N/A 04 (Read Registers) N/A
0x3033 UID (bytes 6 and 7) N/A 04 (Read Registers) N/A
0x3034 UID (bytes 8 and 9) N/A 04 (Read Registers) N/A
0x3035 UID (bytes 10 and 11) N/A 04 (Read Registers) N/A
0x3036 UID (bytes 12 and 13) N/A 04 (Read Registers) N/A
0x3037 UID (bytes 14 and 15) N/A 04 (Read Registers) N/A
Request: Read the part number of the installed cartridge
0x3038 Part number (bytes 0 and 1) N/A 04 (Read Registers) N/A
0x3039 Part number (bytes 2 and 3) N/A 04 (Read Registers) N/A
0x303A Part number (bytes 4 and 5) N/A 04 (Read Registers) N/A
0x303B Part number revision level N/A 04 (Read Registers) N/A
Request: Read the amperage for which the installed cartridge is rated
0x303C Nominal current Amperes 04 (Read Registers) N/A
Request: Read the total cut counts for the installed cartridge
0x3040 Total number of starts Number 04 (Read Registers) N/A
0x3041 Cumulative pilot arc time Seconds 04 (Read Registers) N/A
0x3042 Total number of arc transfers Number 04 (Read Registers) N/A
0x3043 Cumulative arc transfer time 2 seconds
per count
04 (Read Registers) N/A
Request: Read the 4 most recent faults for the installed cartridge
0x3044 Fault log 0 (newest fault) N/A 04 (Read Registers) N/A
0x3045 Fault log 1 N/A 04 (Read Registers) N/A
0x3046 Fault log 2 N/A 04 (Read Registers) N/A
0x3047 Fault log 3 N/A 04 (Read Registers) N/A
Request: Read the 12-character name of the installed cartridge
0x3048 Name (bytes 0 and 1) N/A 04 (Read Registers) N/A
0x3049 Name (bytes 2 and 3) N/A 04 (Read Registers) N/A
0x304A Name (bytes 4 and 5) N/A 04 (Read Registers) N/A
0x304B Name (bytes 6 and 7) N/A 04 (Read Registers) N/A
0x304C Name (bytes 8 and 9) N/A 04 (Read Registers) N/A
0x304D Name (bytes 10 and 11) N/A 04 (Read Registers) N/A
SYNC
Address
Description Unit
Recommended Modbus
Function (hex)
Old
Address
