4. Prior to moving the gate, make sure the wheel clamp spring is compressed to 2 inches (5 cm).
5. Cycle test the gate by pressing the CLOSE and OPEN buttons. Allow the gate to continue traveling
throughout its entire range while you or your assistant check the following:
• Gate handing is set correctly. See product literature for information on gate handing.
• Horizontal rail surface is 9¼ in. ± ½ in. (23 cm ± 1 cm) above the pad over full gate travel. Keep in mind,
if using XtremeDrive™, the placement of the drive rail is ¼ to ½ inch higher.
• Rail ange, attached to the gate supports, remains at a distance of 1¾ in. ± 1/8 in.
(4 cm ± 3 mm) from the outside edge of the operator (edge closest to the gate panel) over the full
range of gate travel.
• Drive wheel face(s) are parallel to the rail ± 1/8 in. (3 mm) with a 2 ft (61 cm) straight edge.
• Limit switches are adjusted to clear the drive rail, but solidly contact the limit ramps.
• Limit ramps are adjusted to stop the gate 1 to 2 inches (2 - 5 cm) from the end of the drive rail.
• Pressure relief valve is properly set. Refer to the yellow tag inside the operator or refer to the product
literature, “Adjusting the Pressure Relief Valve” on page 24.
6. Peripherals, accessories, safety devices, and options have been installed and tested.
7. Check all those that apply:
Free exit Inside Obstruction Loop Outside Obstruction Loop
Open edge Close edge Open photo eye Close photo eye
Stop input (1) Local Open (2) Close timer set (3) Radio open (4)
IES sensor Fire Dept. Open Emergency Close Solenoid lock
WARNING placards mounted on both sides of the gate within sight of vehicle and pedestrian trafc per
UL 325 standards.
Date:
Operator Serial Number: ____________________________________________________________________
Installer Name (please print): _________________________________________________________________
End user’s name (please print): ________________________________________________________________
Site address: _______________________________________________________________________________
___________________________________________________________________________________________
___________________________________________________________________________________________
___________________________________________________________________________________________
Notes: ____________________________________________________________________________________
___________________________________________________________________________________________
___________________________________________________________________________________________
94 D0559 Rev. A SlideDriver/SlideDriver 50VF Series www.hysecurity.com
