126 MX3630-01 Rev. J SlideDriver/SlideDriver 50VF Series © 2019 www.hysecurity.com
Grooved Drive Rail
The grooved drive rail has become the standard for all SlideDriver gate operator installations.
The anged drive rail is only used when a Solenoid Lock option is installed.
The grooved drive rail has replaced the non-grooved, anged drive rail.
A section of the two different drive rails is shown in the illustration.
Standard grooved drive rail Non-grooved, flanged drive rail
No anges
Grooves on the underside
NOTE: Solenoid Lock option
requires anged drive rail
Grooved versus non-grooved, flanged drive rail
The small grooves on the underside of the drive rail improve traction in slick or wet conditions and provide
more pulling and stopping power in SlideDriver installations. The three underside anges have been
eliminated which reduces drive wheel wear and drag in misaligned gate installations. Additionally, the no-
ange drive rail stacks better for shipping which reduces the likelihood of freight damage.
NOTE: The non-grooved, anged drive rail is still available for use with the Solenoid Lock option. The Solenoid Lock option requires
an outer edge ange and therefore must be installed with the non-grooved, anged drive rail.
