HySecurity SlideDriver 40 User Manual

24V
A
C A
cce
s
s
or
y powe
r
+
24
V
D
C
STOP BUTTON
OPEN BUTTON
CLOSE BUTTON
REMOTE OPEN AND
RADIO CONTROL
OPEN/CLOSE
1
OPEN PARTIAL
INTERLOCK OPEN
TIME CLOCK OPEN
FREE EXIT DETECTOR
DISABLE EXIT DETECTOR
DISABLE CLOSE TIMER
INSIDE OBSTRUCTION
VEHICLE DETECTOR
OUTSIDE OBSTRUCTION
VEHICLE DETECTOR
SHADOW/RESET
VEHICLE DETECTOR
SENSOR 1
SENSOR
COM
DO NOT USE
SENSOR 2
DO NOT USE
SENSOR 3
DO NOT USE
CHARGER
AC LOSS
LOCK INTERLOCK
EMERG CLOSE
FIRE DEPT OPEN
2
3
4
5
6
7
8
9
10
11
12
14
15
16
17
18
19
20
21
22
23
24
Smart Touch Controller
LIMIT DUAL GATE
RADIO OPTIONS
DRIVE
POWER
RS485
MOTOR USER 1
USER 2
USER 3
VEHICLE DETECTORVEHICLE DETECTORVEHICLE DETECTOR
STOP/BUZZER
FREE EXIT
INSIDE OBSTR
OUTSIDE OBSTR
SHADOW RESET
WIEGAND
HySecurity
COM
NO
MX000585
VERSION
S/N
RS232
DISPLAY
VEHICLE DETECTOR
COM COMA B
RPM
COMOPEN
S 1
+24V +24V
STAT U S
LED
S2 0
SENSOR #2 TYPE
S2 3 (EDGE CLOS)
SENSOR #2 TYPE
S1 0
SENSOR #1 TYPE
S1 6 (EDGE BOTH)
SENSOR #1 TYPE
Power
SENSOR COM
P/N MX4018
CH1
EDGE 1
SOLID RED = EDGE TRIP
FLASHING = FAULT
FLASHING GREEN
Actively Monitoring
CH1
CH2
CH2
EDGE 2
YL = CH1
BL = CH2
Class 2 Device 10k & 8.2k Ohm
30V, 20 mA Max., NC Output
Smart Touch: 2 CH Wired Edge with Hy2NC
The wiring diagram illustrates a WIRED edge receiver connected to the
STC controller via the 2 channel Wired Edge Sensor N/C adapter Hy2NC™.
NOTE: Turn OFF AC power before connecting sensor wires to the Smart Touch Controller.
CAUTION
Connect all contact and non-contact sensors to same power source.
Example, Do NOT connect photo eyes to +24VDC and gate edges to
+12VDC. Incompatible electricity ow. A FAULT 2 will appear.
CAUTION
All external entrapment protection sensors must be NC sensor
outputs and wired to the SENSOR COM terminal for monitoring
and powering purposes. The sensor becomes actively powered
when the gate operator receives a run command.
Red wire
Power +24V
Red wire SENSOR COM
The sensors do not become active until the motor
runs. For temporary power to the sensors, turn ON
Photo Eye Align mode (PE)in the User Menu.
NOTE: Red wires are
not polarity sensitive.
Yellow wire SENSOR connection for CH 2
Blue wire
SENSOR Connection for CH 1
Sample:
Installer Menu Settings
Channel wires to 10k Edges
CH 2 Wires to Edge Sensor
www.hysecurity.com © 2019 Wiring HySecurity Sensors: Smart Touch MX3630-01 Rev. J 133
