HySecurity SlideDriver 40 User Manual

www.hysecurity.com © 2019 Display & Menu Options MX3630-01 Rev. J 61
Installer Menu Setting Options Menu Tasks & Explanations STC Wire
Connections
DG 0 (OFF)
DUAL GATE
0 = solo operator (off)
1 = Secondary unit
2 = Primary unit
3 = Sally Port A
4 = Sally Port B
Congures gate operator as a Primary or
as a Secondary in a dual-gate installation.
When you assign one unit as Primary, you
must congure other as Secondary through
Installer Menu. This menu is also used to
congure a Sally Port system by setting one
operator to Sally Port A and the other to
Sally Port B.
Dual Gate COM
(Gate 1) to Dual
Gate COM
(Gate 2)
A to A
B to B
SG 0 (OFF)
SEQUENCED GATE
0 = off
1 = Loop View #1
2 = Loop View #2
3 = Loop View #3
4 = Loop View #4
Establishes communication after wiring two
gate operators as sequential gates.
This SG menu item only appears if the
Dual Gate menu item (DG) is set to 0 (solo
operator).
NOTE: After selecting SG settings, consider
accessing the User Menu in each gate
operator to address the Close Timer (CT)
setting.
Connect Dual
Gate COM
(Trafc Gate) to
Dual Gate COM
(Security Gate)
A to A
B to B
CH 0 (AC)
CHARGER TYPE
0 = AC powered charger
1 = Solar powered charger
Assigns charger type usually set at factory. If
set to solar at factory then this menu item is
hidden.
FO 0 (DISABLED)
FIRE DEPT OPEN
0 = disabled
1 = enabled
Provides the Fire Dept. Open input. When
set to 1, the open signal received by the
operator overrides all photoelectric eyes and
edge sensors, and opens the gate. Pressing
the Open or Reset button is required before
the gate can be closed.
+24V
Fire Dept Open
(#24)
OC 0 (DISABLED)
EMERGENCY CLOSE
0 = disabled
1 = enabled
Enables the Emergency Close input. When
set to 1, the constant hold close overrides
vehicle detectors, photo eyes and edge
sensors, and closes the gate. Pressing the
Reset button once or the Open button twice
is required before the gate will open.
+24V
EMERG CLOSE
(#23)
SE 2
IES SENSITIVITY
1 = maximum sensitivity
2 = default sensitivity
9 = lowest sensitivity
Adjusts the sensitivity of the inherent
entrapment sensor. Available settings
are 1-9 with 9 being the least sensitive.
HySecurity strongly recommends that you
avoid setting IES sensitivity higher
than 6.
NOTE: Before changing IES sensitivity,
make sure that gate rolls smoothly without
obstruction. Fix any issues with gate
hardware.
N/A
SS 0
IES STOP ONLY
0 = (off) Stop and reverse for 2s
1 = (on) stop only
A setting of 0, stops the gate and then
reverses its direction of travel for 2 seconds.
To stop gate travel with no reversal, the
optional setting 1 can be selected if the gate
operator is at a Usage Class IV site and
assigned a UC 4 classication.
N/A
LC 0
LEAF DELAY CLOSE
0 = none
1 through 20 in ½
second increments
For example:
1 = ½ second
10 = 5 seconds
20 = 10 seconds
Only appears if gate operator is set up as a
Primary or a Secondary. Available settings
are 1 through 20. Each increment adds ½
second time delay following a command to
close before operator begins closing.
Provides up to a 10 second time delay.
