2-1
032-0330-EN Rev K
Chapter
2
Calibration and Laser
Adjustments
Calibrations are accessed from the Utilities menu in SmartScan STUDIO. See Service Menu Options
chapter for instructions on logging in and accessing Utilities.
NOTE: Ensure scanner is mounted to the wall before beginning calibrations. This should have been
completed during the Level Gantry procedure.
Calibrations and adjustments should be performed in the following order:
1. Panel Calibration
2. Crosshair Laser Adjustment
3. Chair Calibration
4. Centerline Laser Adjustment
5. Geometric Calibration (run with cover off for adjustments, re-run with cover installed)
6. Shutter Calibration
7. Head Holder Alignment
NOTE: The panel cover fits very tightly over the receptor panel. If the panel cover is removed and
re-installed for any reason, perform items 2 - 5.
CAUTIONCAUTION
If the optional deadman handswitch is installed on the scanner, press and hold handswitch before
pressing the Scan button, and continue to hold handswitch down for the duration of the exposure
(X-ray light on). Early release of the handswitch stops the exposure and the Fault light turns on.
The patient will have to be re-scanned.
