i-CAT FLX - Scenario 3 - New DEXIS - i-CAT FLX Installation

3-13
Load Clinical Software and Configure System
032-0330-EN Rev K
Scenario 3 - New DEXIS - i-CAT FLX Installation
NOTE: DEXIS is optional software and is not available in all countries.
Below is the installation sequence of system software. The diagram shows a possible site configuration with
guidelines for the software that should be loaded on each workstation.
5
Install SmartScan STUDIO Client Components (page 3-21) on workstations in front office,
operatories, and consultation rooms.
• SmartScan STUDIO Manager (required by all sites)
• PACS QR (sites using a PACS for image storage)
• PACS MWL (sites using modality worklists for scheduling patients)
• Legacy Practice Management Viewer Launcher (sites using PM system)
6
Install InVivoDental Software (page 3-24) as required.
If not already loaded, load on the workstation where the site will be viewing QA Tests.
Load on workstations that will be using it to view patient images, as purchased by the site.
NOTE: Vision is not supported on the i-CAT FLX, only TxSTUDIO and Dolphin viewers are
supported.
Reception Area
• Approved PMS
• DEXIS Eleven (Client)
• DEXIS i-CAT FLX Client
Site Provided Server
• DEXIS Core (Server)
• SmartScan STUDIO
Integration Services
• DEXIS i-CAT
FLX Server Plugin
• (Optional) 4 - 5 if server
is also a client
i-CAT FLX
• SmartScan STUDIO
(pre-installed)
Operatory/Consultation Room
• DEXIS Eleven (Client)
• DEXIS i-CAT FLX Client
• SmartScan STUDIO Manager
• TxSTUDIO
3
1
2
2
4
5
2
4
