i-CAT FLX - Installation Check for a DEXIS i-CAT FLX Installation

3-32
i-CAT FLX Installation Manual
032-0330-EN Rev K
Installation Check for a DEXIS i-CAT FLX Installation
1. Start DEXIS.
2. In DEXIS, enter data for a test patient.
a. Select New Patient.
b. Enter data for the patient and exam. Example: Enter Test for Last Name and Patient for
First Name.
c. Select OK.
d. Click (Extra-oral) and click I Accept on disclaimer pop-up message.
e. Click . Click Later on registration pop-up message.
f. A pop-up message displays that patient is scheduled for acquisition. Click OK to dismiss.
3. In SmartScan STUDIO, capture a scan for test patient.
a. Set up a phantom in the scanner.
b. At scanner controller, access Acquire option.
c. Select Test Patient from Scheduled Exams list and press .
d. Select a protocol and press .
e. Take a scan.
f. Review image and press to complete.
4. In DEXIS, locate Test Patient exam in Extra-oral display.
5. Double-click the i-CAT box to start TxSTUDIO and load exam.
6. View scan in TxSTUDIO and ensure correct path to the TxSTUDIO Cases
folder displays in File Manager.
