1. Specifi cations Check
1. Specifi cations Check
1.1 Product Check
This product is comprised of the following parts if it is of standard confi guration.
If you fi nd any fault in the contained model or any missing parts, contacts us or our distributer.
1.1.1 Parts
No. Part Name Model
1 Controller [Refer to “1.1.4 How to read the model plate”]
Accessories
2 I/O Flat Cable
Standard type CB-APSEP-PIO*** (***shows the cable length)
Dust-proof type
(Equivalent to IP53)
CB-APSEPW-PIO*** (***shows the cable length)
3 Power Connector MC1.5/5-ST-3.5 (PHOENIX CONTACT)
4 Spacer PFP-S (OMRON)
5
Absolute Battery Unit
(For Simple Absolute Type Only)
SEP-ABUM (Standard type)
SEP-ABUM-W (Dust-proof type)
6 Instruction Manual (This Manual)
7 Instruction Manual (CD/DVD)
8 Safety Guide
1.1.2 Teaching Tool (to be purchased separately)
For the setups such as position setting and parameter setting using the teaching operation, the teaching tool
is required. Please prepare either of the following teaching tools.
No. Part Name Model
1
PC Software (Includes RS232C Exchange Adapter

External Machine
Communication Cable)
RCM-101-MW
2
PC Software (Includes USB Exchange Adapter

USB Cable

External
Machine Communication Cable)
RCM-101-USB
3
Teaching Pendant (Touch Panel Teaching)
CON-PTA
4
Teaching Pendant (Touch panel teaching equipped with a dead man’s
switch)
CON-PDA
5
Teaching Pendant (Touch panel teaching equipped with a dead man’s
switch

TP adapter (RCB-LB-TG))
CON-PGA
6
Teaching Pendant dedicated for SEP Controller (Touch Panel Teaching)
SEP-PT
7
Teaching Pendant (Touch Panel Teaching)
CON-PT
(Note 1)
8
Teaching Pendant (Touch panel teaching equipped with a dead man’s
switch)
CON-PD
(Note 1)
9
Teaching Pendant (Touch panel teaching equipped with a dead man’s
switch

TP adapter (RCB-LB-TG))
CON-PG
(Note 1)
Note 1) It is not applied for DSEP.
