3. Operation
3. Operation
3.1 Setting
3.1.1 Initial Setting
Conduct the following initial settings on the PC software or Touch Panel Teaching.
Refer to the Instruction Manual for the PC software or Touch Panel Teaching for the details of the
settings.
• Initial Setting Items
* There may be some items that are not displayed depending on the selected operation patterns.
No. Setting Items
Setting Range
(Set in delivery)
Contents
PIO Pattern
012345
1 PIO Pattern
(Operation
Pattern)
0 to 5 (0) Set it to the pattern to be used.
○○○○○○
2 Operation
Mode
(Solenoid
System)
Single/Double
(Double)
It is selectable only when the PIO pattern is set to “0”,
“1” or “2”. Select “Single” (Single Solenoid System) or
“Double” (Double Solenoid System).
○○○
3 Stop Signal Enable/Disable
(Disable)
It is selectable only when “Single” is selected in “2.
Operation Mode (Solenoid System)”.
When the PAUSE signal (*STP) is used, select
“Enable”.
○○○ ○
4 Input Signal
System
(Solenoid
Type)
Continuous
Operation Type
/Momentary
Operation Type
(Continuous
Operation Type)
It is selectable only when “Double” is selected in “2.
Operation Mode (Solenoid System)”.
For the signal sent from PLC to ASEP, PSEP or
DSEP, select “Continuous Operation” (level signal) or
“Momentary Operation” (edge signal).
○○○ ○
5 Intermediate
Stop System
Both Solenoids
ON
/Both Solenoids
OFF
(Both Solenoids
OFF)
It is selectable only when the PIO pattern is set to “3”.
In the case the same use procedure as for 5-port
3-position electromagnetic valve is applied, select
“Both Solenoid OFF”.
In the case that the same use procedure as the
time when two units of the 3-port single solenoid
electromagnetic valve, are used, select “Both
Solenoid ON”.
○
6 Servo-motor
Control
Enable/Disable
(Disable)
When “Disable” is selected, the servo-motor is
automatically turned ON after the power input.
When “Enable” is selected, the servo-motor is turned
ON by means of turning ON the SON signal on
INPUT IN3.
○○○○○○
7 Home
Position
Operation
(Home
Return
Operation
Procedure)
AUTO/MANU
(MANU)
If AUTO is selected, the home-return operation is
started automatically when the servo is turned for the
fi rst time after the power is supplied. When “MANU” is
selected, the home return operation is performed with
the fi rst ST0 input.
○○○○○○
