42
/
2. Wiring
2.4.2 Wiring Layout of FG Terminal Block
FG is to be connected to a screwless terminal block.
Strip the sheath of the applicable wires for 11mm and insert them to the connector. Push a protrusion
beside the cable inlet with a small slotted screwdriver to open the inlet. After inserting a cable, remove
the screwdriver from the protrusion to fi x the cable.
● FG Terminal Block
Terminal Block Name FG
Controller Side ML-800-S1H1P
Pin No. Signal Name Contents Applicable Cable
1 FG Ground Cable Connection KIV1.25mm
2
(AWG16)
To Next Page
