45
/
2. Wiring
2.4.5 SIO Connector Connection
SIO connectors can be used not only for the connection of teaching tool, but also for the
connection of the host controller (PLC, touch panel and PC).
For the operation, refer to the instruction manual of each module.
[Refer to Instruction manuals related to this product, which are contained in CD/DVD.]
PC
Touch Panel
Teaching
Note:
If the teaching pendant is removed with the power supply being on, the condition will become the transient
emergency stop and the operated actuator will stop.
Do not disconnect the teaching pendant during the operation.
To Next Page
