IAI ASEP User Manual

99
/
4. Appendix
• The correlation of the pressing force and the current limit
value is the rated pressing speed (in the setting at the
delivery) and is a reference value.
• Use the actuator with the setting above the minimum
pressing force value. The pressing force will be unstable
if it is below the minimum pressing force value.
• Do not change the pressing speed (Parameter No.7).
Please contact and inform us if a change is necessary.
• If the positioning speed setting in the operation condition
is made lower than the pressing speed, the pressing
speed will follow that speed, thus cannot perform the
expected pressing force.
Note
RCP2 Series
RA2C Type
RA3C/RGD3C RA4C/RGS4C/RGD4C RA6C/RGS6C/RGD6C
Rod Type
High Speed TypeMedium Speed TypeLow Speed Type
Pressing Force (N)
Current Limit Value (Ratio %)
Pressing Force (N)
Current Limit Value (Ratio %)
Pressing Force (N)
Current Limit Value (Ratio %)
Pressing Force (N)
Current Limit Value (Ratio %)
Pressing Force (N)
Current Limit Value (Ratio %)
Pressing Force (N)
Current Limit Value (Ratio %)
Pressing Force (N)
Current Limit Value (Ratio %)
Pressing Force (N)
Current Limit Value (Ratio %)
Pressing Force (N)
Current Limit Value (Ratio %)
4.2 Pressing Force and
Current Limit Value
