Figure 56. Switch labels
Specications of the 5149-N64 switch
The following specications provide brief information about the 5149-N64 switch.
System dimensions and weight
System weight and dimensions are listed in the following table:
Height
(1U rack standard)
Width
(19" rack standard)
Depth Weight
4.36 cm (1.7 in) 43.8 cm (17 in) 66.04 cm (26 in) 14.5 kg (31.97 lb)
Note: Two people are required to lift the switch above 1.4 m (57 in). Check the TDA document to identify
where the switch will be installed. Installation locations at 32U and higher require two people to lift the
switch. For installation locations less than 32U, one person can safely lift the switch.
Air temperature
Air flows from the power side of the switch to the port side (power-to-connector (P2C) air flow
conguration). Temperature requirements for the switch are listed in the following table:
70
