Shock and vibration specications for IBM Storage Scale System 3500 enclosures
Table 15 on page 37 and Table 16 on page 37 provide the shock and vibration testing results for your
IBM Storage Scale System 3500 system.
Table 15. Shock testing results
Shock categories Test level Sweep rate of shocks
Operational 5 g 11 ms 1/2 Sine
3 positive shocks
3 negative shocks
Non-operational 10 g 11 ms 1/2 Sine
3 positive shocks
3 negative shocks
Table 16. Vibration testing results
Vibration categories Test level Frequency range
Operational 0.10 g Swept Sine 5 - 500 Hz
Non-operational 0.75 g Swept Sine 5 - 500 Hz
Operating random
vibration
0.15 g 5 - 500 Hz
Non-operating random
vibration
0.5 g 5 - 500 Hz
Table 17. Random vibration PSD prole breakpoints
1
Class 5 Hz 17 Hz 45 Hz 48 Hz 62 Hz 65 Hz 150 Hz 200 Hz 500 Hz
V1L/V2 2.0x10⁻⁷ 2.2x10⁻⁵ 2.2x10⁻⁵ 2.2x10⁻⁵ 2.2x10⁻⁵ 2.2x10⁻⁵ 2.2x10⁻⁵ 2.2x10⁻⁵ 2.2x10⁻⁵
V1H ² 1.0x10⁻⁷ 5.2x10⁻⁶ 5.2x10⁻⁶ 5.2x10⁻⁶ 5.2x10⁻⁶ 5.2x10⁻⁶ 5.2x10⁻⁶ 5.2x10⁻⁶ 5.2x10⁻⁶
V3 2.0x10⁻⁵ 3.0x10⁻⁴ 3.0x10⁻⁴ 3.0x10⁻⁴ 3.0x10⁻⁴ 3.0x10⁻⁴ 3.0x10⁻⁴ 8.0x10⁻⁵ 8.0x10⁻⁵
V5L 2.0x10⁻⁵ 1.1x10⁻³ 1.1x10⁻³ 8.0x10⁻³ 8.0x10⁻³ 1.0x10⁻³ 1.0x10⁻³ 5.0x10⁻⁴ 5.0x10⁻⁴
V5H 1.0x10⁻⁵ 4.0x10⁻⁴ 4.0x10⁻⁴ 3.0x10⁻³ 3.0x10⁻³ 5.0x10⁻⁴ 5.0x10⁻⁴ 2.0x10⁻⁴ 2.0x10⁻⁴
Note:
• ¹ All values in this table are g²/Hz.
• For reference only, no test required.
IP address allocation and usage
As you plan your installation, you must consider IP address requirements and service access for the
system.
IBM Storage Scale System 3500 uses 100GbE/200GbE/100Gb EDR/200Gb HDR network for
cluster communication and data transport. For IP port usage requirement, see IBM Storage Scale
Documentation.
For conguration and management, you must allocate an IP address to the system. This IP address is
referred to as the management IP address. The storage system also has a BMC IP address, which is
known as the service IP address. The addresses must be xed. Only IPv4 addresses are supported for
management and service.
Chapter 3. Planning for hardware
37
