Operator Panel Error Codes
Attention: If you replace FRUs or perform an action and the problem is still not
corrected, go to “MAP 1540: Minimum Configuration” on page 113 unless otherwise
indicated in the tables.
If you replace FRUs and the problem is corrected, go to ″MAP 410: Repair Checkout″
in the
RS/6000 and
Eserver
pSeries Diagnostics Information for Multiple Bus Systems
.
Table 3. Operator Panel Error Codes.
Error Code Description Action/
Possible Failing FRU
0000 1111 At power on, failure of power-good signal
from power supply.
1. Primary I/O backplane
Location: U0.1-P1
2. Primary I/O power supply
Locations:
U0.1-V1
U0.1-V2
0000 1112 At power off, failure of power-good signal
from power supply.
1. Primary I/O backplane
Location: U0.1-P1
2. Primary I/O power supply
Locations:
U0.1-V1
U0.1-V2
0000 1113 While power on, failure of power-good
signal from power supply.
1. Primary I/O backplane
Location: U0.1-P1
2. Primary I/O power supply
Locations:
U0.1-V1
U0.1-V2
0000 1114 Operator panel and service processor
have been reset after main power
disturbance.
Information message
0000 2222 Operator panel not communicating with
service processor
1. If system cannot be powered
off, reset the service processor
(via the pinhole reset or by
disconnecting then
reconnecting power).
2. Primary I/O backplane
Location: U0.1-P1
0000 3333 SPCN communications error Primary I/O backplane
Location: U0.1-P1
0000 3334 I2C repeater error Primary I/O backplane
Location: UO.1-P1
0000 BBBB TOD battery malfunction TOD battery
Location: U0.1-P1-V3
168 Service Guide
