11. Loosen the two screws from the center cover and remove the cover.
Center
Cover
Media
Cable
Tray
12. Remove the media cable tray.
13. Remove the screws from the power distribution board.
Power
Distribution
Board
14. Remove the power distribution board.
Replacement
Replace in reverse order.
Chapter 9. Removal and Replacement Procedures 453
