SCSI IDs and Bay Locations
The following figure shows the SCSI IDs for media devices. The SCSI IDs for media
devices installed at the factory are set using jumpers on the drives when they are
installed. The SCSI IDs are set as shown in the following figure.
1
2
R
Note: The SCSI IDs shown for media devices indicate how the IDs are set when the
system is shipped from the factory.
1 CD-ROM drive (SCSI
ID= 1)
2 Tape drive (SCSI ID=
0)
Chapter 1. Reference Information
25
