One-Way Processor Card Memory DIMM Locations
(8) A
(7) B
(6) C
(5) D
(3) C
(4) D
(2) B
(1) A
Location Code Memory DIMMs
U1.1-P1-C1-Mn Memory DIMMs on processor card (n denotes
DIMM number)
U1.1-P1-C1-M1 x2 Memory pair A (DIMMs 1 and 8)
U1.1-P1-C1-M2 x2 Memory pair B (DIMMs 2 and 7)
U1.1-P1-C1-M3 x2 Memory pair C (DIMMs 3 and 6)
U1.1-P1-C1-M4 x2 Memory pair D (DIMMs 4 and 5)
U1.1-P1-C1-M1 x8 All memory DIMMs on processor card
22 Service Guide
